Industrial Sensor

• Accuracy
• 7.5 W/m8

• Application
• Solar PV system monitoring, meteorological stations

• Cable Length
• 5 meters

• Features
• Weatherproof, compact design, robust build, fast response

• Function
• Measures solar irradiance (W/m8) for PV performance monitoring

• Housing Material
• Anodized aluminum

• IP Rating
• IP67

• Ingress Protection
• IP67

• Input
• Solar irradiance

• Interface
• 2-wire voltage output

• Material
• Aluminum & optical-grade glass

• Measurement Range
• 0 to 2000 W/m8

• Mounting Thread
• 1/4-20 UNC

• Mounting Type
• Standard screw mount

• Operating Temperature
• -406C to +856C

• Output
• Analog voltage

• Power Consumption
• < 1 mW

• Product Type
• Pyranometer Sensor

• Resolution
• 1 W/m8

• Response Time
• < 1 ms

• Sensitivity
• 0.2 mV per W/m8

• Sensor Type
• Silicon photovoltaic diode

• Signal Type
• Other, Analog DC

• Spectral Range
• 400 to 1100 nm

• Usage
• Solar energy, photovoltaic testing, environmental monitoring

• Voltage
• 5 V DC nominal

• Weight
• 280 grams

• Wireless
• No

• Accuracy
• 2% (relative to NREL-calibrated reference)

• Application
• Photovoltaic System Monitoring, Irradiance Measurement

• Cable Length
• 5 m

• Features
• Calibrated to global reference (IEC 60904-2), Field replaceable, Rugged design

• Function
• Measures reference solar irradiance

• Housing Material
• Anodized Aluminum

• IP Rating
• IP65

• Ingress Protection
• IP65

• Input
• Solar Irradiance

• Interface
• 2-wire Analog

• Material
• Monocrystalline Silicon

• Measurement Range
• 0-1500 W/m2

• Mounting Thread
• 1/4-20 UNC

• Mounting Type
• Panel Mount, Threaded

• Operating Temperature
• -40C to 85C

• Output
• Analog Voltage

• Power Consumption
• Passive/No external power required

• Product Type
• Reference Cell Sensor

• Resolution
• 1 W/m2

• Response Time
• < 5 ms

• Sensitivity
• 1-2 V/(W/m2)

• Sensor Type
• Monocrystalline Silicon Reference Cell

• Signal Type
• Analog

• Spectral Range
• 300-1200 nm

• Usage
• PV System Performance Monitoring

• Voltage
• 0-200 mV (typical analog output)

• Weight
• Approx. 400 g

• Wireless
• No
