Compact Weather Sensors

• Accuracy
• Wind 0.2 m/s (0-35 m/s); Temperature 0.2 C; Relative Humidity 2% (10-90% RH); Air Pressure 0.5 hPa

• Application
• Weather stations, environmental monitoring, industrial and research use

• Cable Length
• As required, typically 5 m supplied

• Features
• All-in-one sensor, maintenance-free operation, compact design, heated precipitation sensor, easy integration

• Function
• Measures multiple weather parameters including wind, precipitation, temperature, humidity, air pressure, brightness, and global radiation

• Housing Material
• Anodized Aluminum / Polycarbonate UV-resistant / Stainless Steel

• IP Rating
• IP66

• Ingress Protection
• IP66

• Input
• 9...32 V DC (Nominal 24 V DC recommended)

• Interface
• RS485, SDI-12, Modbus

• Material
• Aluminum, Polycarbonate, Stainless Steel

• Measurement Range
• Wind: 0-75 m/s; Temp: -40 to +60 C; RH: 0-100%; Pressure: 600-1100 hPa; Precipitation: quantity + intensity

• Mounting Thread
• 1.5 / 2 (approx. 48mm/60mm) mounting adapter

• Mounting Type
• Pole mount / adapter mount

• Operating Temperature
• -40 to +60 C

• Output
• UMB-Binary, UMB-ASCII, SDI-12, Modbus, 2 analog outputs

• Power Consumption
• Max. 4.8 W

• Product Type
• Smart Weather Sensor

• Resolution
• Wind 0.1 m/s; Temperature 0.1 C; Relative Humidity 0.1%; Air Pressure 0.1 hPa

• Response Time
• Wind <0.25 s; Temperature <30 s; Humidity <10 s

• Sensitivity
• 0.1 m/s (wind); 0.1 C (temp); 0.1% RH

• Sensor Type
• Ultrasonic (winds) / Capacitive (humidity) / Precision thermistor (temperature) / Photodiode (brightness)

• Signal Type
• Other, Digital and analog

• Spectral Range
• Instrument specific, general 300-1100 nm for radiation sensor

• Usage
• For professional meteorological monitoring

• Voltage
• 9-32 V DC

• Weight
• Approx. 0.8 kg

• Wireless
• No

• Accuracy
• Wind speed: 0.2 m/s, Precipitation: 3%

• Application
• Agriculture, Meteorology, Industry, Research

• Cable Length
• 10 meters standard

• Features
• Compact, maintenance-free, all-in-one design

• Function
• Measures various meteorological parameters

• Housing Material
• Plastic Housing

• IP Rating
• IP66

• Ingress Protection
• IP66

• Input
• 9-30 VDC

• Interface
• RS485, UMB, MODBUS

• Material
• UV-Stabilized Polycarbonate

• Measurement Range
• Wind: 0-75 m/s, Temp: -40C to +70C, Humidity: 0-100%

• Mounting Thread
• 1.5 (Adapter available for other sizes)

• Mounting Type
• Pole Mount

• Operating Temperature
• -40C to +70C

• Output
• RS485, MODBUS, UMB Protocol

• Power Consumption
• <2 W

• Product Type
• Smart Weather Sensor

• Resolution
• Wind: 0.1 m/s, Temperature: 0.1C, Humidity: 0.1%

• Response Time
• 1 Second

• Sensitivity
• Wind: 0.05 m/s

• Sensor Type
• Ultrasonic / Capacitive / Electronic

• Signal Type
• Digital

• Spectral Range
• 400-1100 nm (for solar sensor types)

• Usage
• Outdoor Weather Monitoring

• Voltage
• 24 VDC (Typical)

• Weight
• Approximately 1.5 kg

• Wireless
• No

• Accuracy
• Wind: 0.3 m/s, Temp: 0.2C, Humidity: 2% RH, Pressure: 0.5 hPa

• Application
• Agriculture, Solar Farms, Meteorological Stations, Industrial Weather Monitoring

• Cable Length
• Customizable, up to 20 m

• Features
• Heated sensor, All-in-one compact design, Maintenance-free

• Function
• Combined measurement of weather parameters

• Housing Material
• Anodized Aluminum and UV-resistant plastic

• IP Rating
• IP66

• Ingress Protection
• IP66

• Input
• Digital/Analog

• Interface
• RS485, UMB

• Material
• Aluminum, Plastic

• Measurement Range
• Wind: 0-75 m/s, Temp: -40C to +60C, Humidity: 0-100% RH, Pressure: 300-1200 hPa

• Mounting Thread
• 1.5 NPT

• Mounting Type
• Pole Mount

• Operating Temperature
• -40C to +60C

• Output
• RS485 Modbus, UMB Protocol

• Power Consumption
• <2 W

• Product Type
• Smart Weather Sensor

• Resolution
• Wind: 0.1 m/s, Temp: 0.1C, Humidity: 0.1% RH

• Response Time
• <1 s

• Sensitivity
• Wind: 0.01 m/s

• Sensor Type
• Ultrasonic, Capacitive, Piezoelectric, Electronic

• Signal Type
• Other, Digital (RS485)

• Spectral Range
• 400 to 1100 nm (Radiation Sensor, if present)

• Usage
• Outdoor Weather Monitoring

• Voltage
• 8-32 V DC

• Weight
• 0.7 kg

• Wireless
• Other, Optional (via external module)

• Accuracy
• Temperature: 0.2C, Wind Speed: 0.2 m/s or 2% of measured value, Humidity: 2% RH, Air Pressure: 0.5 hPa

• Application
• Weather Stations, Solar Parks, Airports, Building Automation

• Cable Length
• Depends on installation; up to 100 m with RS485

• Features
• Compact, maintenance-free, no moving parts, integrated heating for precipitation sensor

• Function
• Measures temperature, humidity, air pressure, wind direction, wind speed, precipitation, and brightness

• Housing Material
• Anodized Aluminum, UV-resistant plastic (ASA) and Stainless Steel

• IP Rating
• IP66

• Ingress Protection
• IP66

• Input
• 24 V DC (9 to 36 V DC)

• Interface
• RS485 (ASCII, MODBUS, UMB, SDI-12)

• Material
• Anodized Aluminum, ASA plastic, Stainless Steel

• Measurement Range
• Temperature: -40...+60C, Wind Speed: 0...75 m/s, Humidity: 0...100% RH, Pressure: 300...1200 hPa, Precipitation: 0...200 mm/h

• Mounting Thread
• 1.5 pipe thread (G 1.5 or 1.5 NPT)

• Mounting Type
• Pipe mount (horizontal or vertical)

• Operating Temperature
• -40C to +60C

• Output
• Digital protocols: RS485 (ASCII, MODBUS, UMB, SDI-12)

• Power Consumption
• max. 4 W

• Product Type
• Smart Weather Sensor

• Resolution
• Temperature: 0.1C, Wind Speed: 0.1 m/s, Humidity: 0.1% RH, Air Pressure: 0.1 hPa

• Response Time
• Wind: 0.25 s, Temperature/Humidity: <1.5 s

• Sensitivity
• Wind Speed: 0.01 m/s, Precipitation: 0.1 mm

• Sensor Type
• Ultrasonic (wind), Capacitive (humidity), PT100 (temperature), Piezoelectric (precipitation)

• Signal Type
• Digital

• Spectral Range
• PAR Sensor: 400-700 nm

• Usage
• Weather monitoring for meteorological, industrial, and infrastructure applications

• Voltage
• 9...36 V DC

• Weight
• Approx. 1.7 kg

• Wireless
• No

• Accuracy
• Wind speed: 0.2 m/s or 2% of reading; Temperature: 0.2C; Humidity: 2% RH; Pressure: 0.5 hPa

• Application
• Industrial, environmental, agriculture, meteorology

• Cable Length
• Default 10 m (other lengths on request)

• Features
• No moving parts, maintenance free, all-in-one sensor, high reliability, suitable for harsh environments

• Function
• Simultaneous measurement of air temperature, relative humidity, air pressure, wind direction/speed, and precipitation intensity/type

• Housing Material
• Anodized aluminum, plastic (polycarbonate) and stainless steel parts

• IP Rating
• IP66

• Ingress Protection
• IP66

• Input
• 12...32 V DC

• Interface
• RS485, SDI-12, UMB, analog output option

• Material
• Weatherproof anodized metal body

• Measurement Range
• Wind speed: 0...75 m/s; Wind direction: 0...359.9; Temperature: -50...+60C; Humidity: 0...100% RH; Pressure: 300...1200 hPa

• Mounting Thread
• Internal thread 1.5 and 1 (adapter included)

• Mounting Type
• Pole or mast-mount

• Operating Temperature
• -50C to +60C

• Output
• RS485 (Modbus RTU), SDI-12, UMB-Binary/ASCII, analog output (optional)

• Power Consumption
• typ. 2.0 W

• Product Type
• Smart Weather Sensor

• Resolution
• Wind speed: 0.1 m/s; Temperature: 0.1C; Humidity: 0.1% RH

• Response Time
• Wind 1 s; Temperature 30 s

• Sensitivity
• Wind: 0.01 m/s; Temperature: 0.1C

• Sensor Type
• Ultrasonic for wind, capacitive for humidity, piezo for precipitation, PT100 for temperature

• Signal Type
• Other, Digital (RS485/SDI-12/UMB), analog (optional)

• Spectral Range
• Visible spectrum for precipitation detection

• Usage
• Weather monitoring for environmental, industrial, and meteorological applications

• Voltage
• 12...32 V DC

• Weight
• Approx. 1.7 kg

• Wireless
• No

• Accuracy
• Temperature: 0.2C, Humidity: 2% RH, Air Pressure: 0.5 hPa, Wind: 0.3 m/s, Precipitation: 5%

• Application
• Meteorological stations, agriculture, building automation, airports

• Cable Length
• Up to 10 m (recommended)

• Features
• Heated sensors, maintenance-free, compact design, no moving parts

• Function
• Measures temperature, humidity, air pressure, wind, precipitation, global radiation

• Housing Material
• Plastic, UV-resistant polycarbonate and aluminum

• IP Rating
• IP66

• Ingress Protection
• IP66

• Input
• 9...24 V DC

• Interface
• RS485, SDI-12, Modbus

• Material
• Polycarbonate, Aluminum

• Measurement Range
• Temperature: -50...+60C, Humidity: 0...100% RH, Wind: 0...75 m/s, Pressure: 300...1200 hPa

• Mounting Thread
• 1.5 pipe thread ( 48 mm)

• Mounting Type
• Pipe, mast or pole mount

• Operating Temperature
• -50C to +60C

• Output
• RS485, Modbus, UMB-ASCII, UMB-Binary, SDI-12

• Power Consumption
• Max. 3 W

• Product Type
• Smart Weather Sensor

• Resolution
• Temperature: 0.1C, Humidity: 0.1% RH, Air Pressure: 0.1 hPa, Wind: 0.1 m/s

• Response Time
• Temperature: <30 s, Humidity: <10 s, Wind: <1 s

• Sensitivity
• Precipitation: 0.01 mm

• Sensor Type
• Compact all-in-one weather sensor with passive and active components

• Signal Type
• Digital

• Spectral Range
• 300-1100 nm (global radiation)

• Usage
• Outdoor environmental monitoring

• Voltage
• 9-24 V DC

• Weight
• Approx. 900 g

• Wireless
• No

• Accuracy
• Wind Speed: 0.2 m/s or 2% (0...35 m/s); Wind Direction: 2; Temperature: 0.2 C; Humidity 2% RH; Pressure 0.5 hPa

• Application
• Weather Station, Agricultural, Renewable Energy, Environmental Monitoring

• Cable Length
• Default 10 m, Customizable

• Features
• No Moving Parts, Maintenance-Free, Heater Option, Compact Design

• Function
• Measures wind speed, wind direction, air temperature, humidity, air pressure, and global radiation

• Housing Material
• Anodized Aluminum, UV-resistant Plastic, Stainless Steel Components

• IP Rating
• IP66

• Ingress Protection
• IP66

• Input
• 12...32 VDC (nominal 24 VDC)

• Interface
• RS485, Analog Output

• Material
• Durable Composite and Metal

• Measurement Range
• Wind Speed: 0...75 m/s; Wind Direction: 0...359.9; Temperature: -50...+60 C; Humidity: 0...100% RH; Pressure: 300...1200 hPa; Radiation: 0...1400 W/m2

• Mounting Thread
• Standard 1.5 Pipe Thread

• Mounting Type
• Pole Mount

• Operating Temperature
• -50...+60 C

• Output
• RS485 (Modbus RTU, UMB-Protocol), Analog

• Power Consumption
• Typical 3 W

• Product Type
• Smart Weather Sensor

• Resolution
• Wind Speed: 0.1 m/s; Wind Direction: 1; Temperature: 0.1 C; Humidity: 0.1% RH; Pressure: 0.1 hPa

• Response Time
• Wind <1 s, Temperature <30 s

• Sensitivity
• Wind: 0.1 m/s; Radiation: 1 W/m2

• Sensor Type
• Ultrasonic (Wind), Capacitive (Humidity), PT100 (Temperature), Piezoresistive (Pressure), Silicon-Photodiode (Radiation)

• Signal Type
• Other, Digital (RS485), Analog

• Spectral Range
• 300...1100 nm (Global Radiation Sensor)

• Usage
• Meteorological Monitoring, Weather Stations

• Voltage
• 12-32 V DC

• Weight
• Approx. 0.8 kg

• Wireless
• Other, Optional (external module required)

• Accuracy
• Wind speed: 0.2 m/s or 2% of reading; Wind direction: 2; Temperature: 0.2 C; Humidity: 2%; Pressure: 0.5 hPa; Radiation: 5%

• Application
• Weather stations, environmental monitoring, renewable energy, meteorology

• Cable Length
• 2 m (standard)

• Features
• No moving parts, compact design, maintenance-free, integrated ventilation/heating

• Function
• Measurement of wind, temperature, humidity, air pressure, global radiation

• Housing Material
• Anodised aluminium, plastic

• IP Rating
• IP66

• Ingress Protection
• IP66

• Input
• 9...24 VDC

• Interface
• RS485 digital

• Material
• Aluminium and Plastic

• Measurement Range
• Wind speed: 0-75 m/s; Wind direction: 0-359; Temperature: -50 to +60C; Humidity: 0-100%; Pressure: 300-1200 hPa; Radiation: 0-1400 W/m2

• Mounting Thread
• G 1.5

• Mounting Type
• Pole/pipe mount

• Operating Temperature
• -50 to +60 C

• Output
• RS485, Modbus, UMB-ASCII, UMB-Binary

• Power Consumption
• max. 3 W

• Product Type
• Smart Weather Sensor

• Resolution
• Wind speed: 0.1 m/s; Temperature: 0.1C; Humidity: 0.1%; Pressure: 0.01 hPa

• Response Time
• Wind: 1 s; Temperature: < 10 s; Humidity: < 10 s

• Sensitivity
• Wind speed: 0.01 m/s

• Sensor Type
• Ultrasonic (wind), Capacitive (humidity), PT100/1000 (temperature), Semiconductor (pressure), Photodiode (radiation)

• Signal Type
• Digital

• Spectral Range
• 300 - 1100 nm (global radiation)

• Usage
• Meteorological/weather monitoring

• Voltage
• 9-24 V DC

• Weight
• Approx. 1.7 kg

• Wireless
• No

• Accuracy
• Temperature: 0.2C (0...50C); Humidity: 2% (0...100% RH); Pressure: 0.5 hPa (800...1100 hPa)

• Application
• Meteorological stations, agriculture, industry, building automation

• Cable Length
• Typically 2.5 m (Optional)

• Features
• Maintenance-free, compact design, rugged, UV-resistant

• Function
• Measuring ambient temperature, relative humidity, air pressure

• Housing Material
• Anodized aluminium, plastic (radiation shield)

• IP Rating
• IP66

• Ingress Protection
• IP66

• Input
• 12...32 V DC

• Interface
• RS485, SDI-12, Modbus, UMB

• Material
• Aluminium, plastic

• Measurement Range
• Temperature: -50C...+60C; Humidity: 0...100% RH; Pressure: 600...1100 hPa

• Mounting Thread
• G 1 (1 inch) thread

• Mounting Type
• Pole mount

• Operating Temperature
• -50C to +60C

• Output
• RS485, Modbus, UMB-Binary, ASCII, SDI-12

• Power Consumption
• < 3 W

• Product Type
• Smart Weather Sensor

• Resolution
• Temperature: 0.1C; Humidity: 0.1% RH; Pressure: 0.01 hPa

• Response Time
• Temperature: <30 s

• Sensor Type
• Capacitive humidity, PT100 temperature, MEMS pressure

• Signal Type
• Digital

• Usage
• Weather monitoring, meteorology, environmental monitoring

• Voltage
• 12 to 32 V DC

• Weight
• Approx. 0.7 kg

• Wireless
• No

• Accuracy
• Temperature: 0.2C; Humidity: 2% RH; Pressure: 0.5 hPa

• Application
• Weather stations, Building Automation, Industrial Monitoring

• Cable Length
• 2 m (default), extendable

• Features
• No moving parts, compact design, maintenance-free

• Function
• Measures ambient temperature, relative humidity, air pressure

• Housing Material
• Polycarbonate (PC), UV-resistant

• IP Rating
• IP66

• Ingress Protection
• IP66/NEMA 4X

• Input
• 24 V AC/DC

• Interface
• RS485 (Modbus RTU)

• Material
• Polycarbonate, Stainless Steel

• Measurement Range
• Temperature: -40C to +60C; Humidity: 0-100% RH; Pressure: 300-1200 hPa

• Mounting Thread
• G 1 thread

• Mounting Type
• Threaded Mount

• Operating Temperature
• -50C to +60C

• Output
• Digital (Modbus RTU, RS485)

• Power Consumption
• < 1.8 W

• Product Type
• Smart Weather Sensor

• Resolution
• Temperature: 0.1C; Humidity: 0.1% RH; Pressure: 0.1 hPa

• Response Time
• Temperature: <10s; Humidity: <8s

• Sensitivity
• High

• Sensor Type
• Capacitive (Humidity), Piezoresistive (Pressure), RTD Pt100 (Temperature)

• Signal Type
• Digital

• Usage
• Outdoor Environmental Monitoring

• Voltage
• 24 V AC/DC (9...28 V)

• Weight
• Approx. 0.7 kg

• Wireless
• No

• Accuracy
• Wind Speed: 0.2 m/s or 2 % (0...60 m/s), Wind Direction: 2, Temperature: 0.2C (-40...60C), Relative Humidity: 2 % RH (0...100 % RH), Pressure: 0.5 hPa (600...1100 hPa)

• Application
• Weather Stations, Industry, Environmental Monitoring

• Cable Length
• Typically 2.5 m (customizable)

• Features
• Maintenance-free, Compact Size, Integrated Digital Diagnostic, Easy Installation, No Moving Parts

• Function
• Measures wind speed, wind direction, air temperature, relative humidity, air pressure, and digital internal diagnostics

• Housing Material
• Anodized Aluminum, Stainless Steel (SUS) and Durable Plastic Housing

• IP Rating
• IP65

• Ingress Protection
• IP65

• Input
• 12...32 VDC

• Interface
• RS485, SDI-12, NMEA, UMB Protocol

• Material
• Weather-resistant Construction

• Measurement Range
• Wind Speed: 0-60 m/s, Wind Direction: 0-359.9, Temperature: -40...+60C, Humidity: 0-100 % RH, Pressure: 600-1100 hPa

• Mounting Thread
• Standard 1 inch (25 mm) Pipe Thread

• Mounting Type
• Pole (Pipe) Mountable

• Operating Temperature
• -40 to +60C

• Output
• Digital: RS485 (Modbus RTU), SDI-12, NMEA 0183, UMB Protocol

• Power Consumption
• <2 W

• Product Type
• Compact Smart Weather Sensor

• Resolution
• Wind Speed: 0.1 m/s, Wind Direction: 1, Temperature: 0.1C, Humidity: 0.1 %RH, Pressure: 0.1 hPa

• Response Time
• Wind: <1 s, Temperature: <30 s, Humidity: <10 s, Pressure: <1 s

• Sensitivity
• Wind: 0.01 m/s, Humidity: 0.1% RH, Temperature: 0.1C, Pressure: 0.1 hPa

• Sensor Type
• Ultrasonic (Wind), Capacitive (Humidity), Pt100/Pt1000 (Temperature), Piezo-resistive (Pressure)

• Signal Type
• Digital

• Usage
• Meteorological and Industrial Weather Monitoring

• Voltage
• 12-32 VDC

• Weight
• Approx. 0.9 kg

• Wireless
• No

• Accuracy
• Wind Speed: 0.2 m/s or 2% (0...35 m/s); Wind Direction: 2 (2...360)

• Application
• Meteorology, Environmental Monitoring, Industrial Applications

• Cable Length
• 2 m, extendable

• Features
• Compact, Maintenance-free, No moving parts, UV-resistant

• Function
• Measures wind speed and wind direction

• Housing Material
• Anodized Aluminum, Plastic (ASA) housing

• IP Rating
• IP66/IP68

• Ingress Protection
• IP66/IP68

• Input
• DC power supply

• Interface
• RS485, SDI-12, Analog

• Material
• UV-stable ASA, Anodized Aluminum

• Measurement Range
• Wind Speed: 0...75 m/s; Wind Direction: 0...359.9

• Mounting Thread
• 1.5 NPT or 1 pipe thread

• Mounting Type
• Pole/wall mount via thread

• Operating Temperature
• -40C to +70C

• Output
• RS485 (Modbus RTU), UMB-ASCII, SDI-12, analog available

• Power Consumption
• <0.5 W

• Product Type
• Smart Weather Sensor

• Resolution
• Wind Speed: 0.1 m/s; Wind Direction: 1

• Response Time
• 1 s

• Sensitivity
• Wind speed: 0.1 m/s start-up

• Sensor Type
• Ultrasonic (No moving parts)

• Signal Type
• Other, Digital (Modbus RTU, SDI-12), Analog optional

• Usage
• Weather monitoring

• Voltage
• Power Supply: 9 to 32 VDC

• Weight
• Approx. 0.5 kg

• Wireless
• No

• Accuracy
• Wind: 0.2 m/s or 2%; Temperature: 0.2C; Humidity: 2% RH

• Application
• Weather monitoring, agriculture, traffic, environmental monitoring

• Cable Length
• Standard 10 m

• Features
• Maintenance-free, compact design, integrated heater for precipitation measurement

• Function
• Measures wind, rainfall, temperature, humidity, air pressure

• Housing Material
• Anodized aluminum, plastic (ASA) and stainless steel

• IP Rating
• IP66

• Ingress Protection
• IP66

• Input
• 24 VDC (20-28 VDC)

• Interface
• RS485, SDI-12, MODBUS, UMB

• Material
• ASA, anodized aluminum

• Measurement Range
• Wind: 0-75 m/s; Temperature: -40 to +60C; Humidity: 0-100% RH; Air pressure: 300-1200 hPa

• Mounting Thread
• 1.5 pipe, 32 mm

• Mounting Type
• Pole or mast mount (32 mm pipe thread)

• Operating Temperature
• -40C to +60C

• Output
• RS485, SDI-12, MODBUS, UMB protocols

• Power Consumption
• Typical 3W

• Product Type
• Smart Weather Sensor

• Resolution
• Wind speed: 0.1 m/s; Temperature: 0.1C; Humidity: 0.1% RH

• Response Time
• Wind: <0.25 sec; Temperature/Humidity: <30 s

• Sensitivity
• Wind: 0.1 m/s

• Sensor Type
• Ultrasonic, electronic, capacitive

• Signal Type
• Other, Digital (RS485, SDI-12, MODBUS, UMB)

• Spectral Range
• 400-1100 nm (solar radiation sensor, if equipped)

• Usage
• Meteorological measurements for weather monitoring

• Voltage
• 24 VDC

• Weight
• Approx. 1.3 kg

• Wireless
• No

• Accuracy
• Wind speed: 0.3 m/s or 3%; Wind direction: 3; Temperature: 0.2C; Humidity: 2% RH; Pressure: 0.5 hPa

• Application
• Weather stations, Building automation, Renewable energy, Transportation

• Cable Length
• Configurable, standard 10 m

• Features
• Maintenance-free, no moving parts, heated sensor head, compact design, easy installation

• Function
• Measures wind speed, wind direction, air temperature, humidity, and air pressure

• Housing Material
• Aluminum, polycarbonate, stainless steel

• IP Rating
• IP66 / IP67

• Ingress Protection
• IP66 / IP67

• Input
• Direct Power Supply

• Interface
• RS485, SDI-12, UMB, NMEA 0183

• Material
• UV-stabilized plastic and anodized aluminum

• Measurement Range
• Wind speed: 0...75 m/s; Wind direction: 0...359.9; Temperature: -40...+60C; Humidity: 0...100% RH; Pressure: 300...1200 hPa

• Mounting Thread
• G 1 (internal), compatible with standard pipe mount and adapters

• Mounting Type
• Pole / Mast Mount

• Operating Temperature
• -40C to +60C

• Output
• RS485 Modbus, ASCII, UMB Protocol, SDI-12, NMEA 0183

• Power Consumption
• Max. 3 W

• Product Type
• Smart Weather Sensor

• Resolution
• Wind speed: 0.1 m/s; Wind direction: 1; Temperature: 0.1C; Humidity: 0.1% RH; Pressure: 0.1 hPa

• Response Time
• <1 s (all parameters)

• Sensitivity
• Wind speed: 0.1 m/s; Wind direction: 1

• Sensor Type
• Ultrasonic wind sensor, capacitive humidity sensor, Pt1000 temperature sensor, MEMS pressure sensor

• Signal Type
• Digital

• Spectral Range
• Not applicable (no irradiance measurement)

• Usage
• Meteorological monitoring, industrial applications, environmental research

• Voltage
• 24V DC (9...28 V DC)

• Weight
• Approx. 0.7 kg

• Wireless
• No
